HARDWARE FEATURES | |
---|---|
Transmission Speeds | Powerline: Up to 1000 Mbps Ethernet: 10/100/1000 Mbps |
Standards and Protocols | HomePlug AV2, HomePlug AV, IEEE 1901, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.11b/g/n (2.4GHz), IEEE 802.11a/n/ac (5GHz) |
Compatibility | Compatible with all HomePlug AV & AV2 standard powerline adapters |
Plug Type | EU |
Interface | TL-WPA7617: 1 Ethernet Port; |
Button | Pair, Reset, Wi-Fi Clone, LED On/Off |
Power Consumption | TL-WPA7617: Maximum: 11W, Typical: 6.5W |
LED Indicator | Power, Powerline, Ethernet, Wi-Fi |
Dimensions ( W x D x H ) | TL-WPA7617: 2.7 × 1.4 × 4.9 in. (69.5 × 35 × 124.1 mm) |
Range | Up to 300 meters/1000 feet over existing electrical wiring |
WIRELESS FEATURES | |
---|---|
Wireless Speeds | Up to 1200 Mbps |
Wireless Security | Wireless: WPA-PSK / WPA2-PSK, WEP Encrptions |
SOFTWARE FEATURES | |
---|---|
Management | tpPLC: Scan the QR code to download TP-Link tpPLC App. Or download new tpPLC Utility on PCs: www.tp-link.com. |
Modulation Technology | OFDM (PLC) |
Encryption | Powerline: 128-bit AES Encryption Wireless: WPA-PSK / WPA2-PSK, WEP Encrptions |
OTHERS | |
---|---|
Certification | CE, RoHS |
Package Contents | AV1000 Gigabit Powerline: TL-WPA7617 Ethernet Cable × 1 Quick Installation Guide |
System Requirements | Windows 10/8.1/8/7/Vista/XP, Mac OS, Linux |
Environment | Operating Temperature: 0°C~40°C (32°F~104°F) Operating Humidity: 10%~90% non-condensing |
