- Boost Clock: Up to 2544 MHz
- Game Clock: Up to 2171 MHz
- Memory: 12GB/192 bit DDR6. 18Gbps Effective
- Stream Processors: 3456
- RDNA™ 3 Architecture
- Ray Accelerator: 54
| Interface |
PCI Express 16x 4.0 |
| Chipset | ATI Radeon RX 7700 XT |
| Memory | 12GB GDDR6 |
| Core Clock | Boost Clock: Up to 2544 MHz Game Clock: 2171 MHz |
| Memory Clock | 18Gbps |
| Stream Processors | 3456 |
| VGA (Max Res) | Not Supported |
| USB C (Max Res) | - |
| HDMI (Max Res) | 2 x HDMI 2.1 Port (7680×4320) |
| DisplayPort | 2 x Displayport 2.1 (7680×4320) |
| Cooling | Dual Fan |
| Power Connection | 2 x 8-pin PCIe power 700W or higher PSU Recommended |
| Card Dimensions | 280mm x 129mm x 52.6mm (LxHxD) |
| Mounting | 2.5 Slots Full Height |
Digital Power Design
SAPPHIRE NITRO+ & PULSE AMD Radeon RX 7700 Series are designed with digital power which provides accurate power control and excellent power efficiency
Ultra High Performance Conductive Polymer Aluminum Capacitor
The Ultra High Performance Conductive Polymer Aluminum Capacitor has a small PCB foot print but high volumetric capacitance that makes 14-phase power possible on the RX 7700 series graphics card. The capacitor offers stable capacitance at a high frequency and temperature with very low signal noise, ensuring the stability and reliability of the product.
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Two-Ball Bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
GPU Series:
RX 7700 XT
Card Length:
280
Displayport:
2
DVI Ports:
0
Fanless:
GTIN:
4895106294288
HDMI Ports:
2
Low Profile :
MPN:
11335-04-20G
VRAM:
12GB
New features
Manufacturer:
Sapphire
