Quickly mount any Kraken X Series liquid cooler onto graphics cards with the Kraken G12 mounting kit. It delivers a 40% increase in cooling capacity over stock cooling, and features a newly designed bracket with an easier installation process versus the Kraken G10. Plus, the G12 is compatible with more than 30 liquid coolers on the market.
Supports the latest Kraken X42/X52/X62/72
Convert GPU’s stock cooling to liquid cooling with 40% increase in cooling capacity
Supports both AMD and NVIDIA graphics cards–reference and most non-reference design
Compatible with over 30 liquid coolers and 40 different GPUs
92mm fan for active VRM cooling with space for aftermarket VRM heatsinks
Dimensions | 201 x 113 x 32 mm |
Material(s) | Steel and Plastic |
Weight | 282 g |
Fan Speed | 1,500 RPM |
Fan Connector | 3-pin |
Fan Bearing | Rifle Bearing |
Fan Rated Voltage | 12V DC, 0.18A, 2.16W |
Compatibility - Graphics Cards | Nvidia GeForce RTX* 2080, 2080 Ti, Titan X, Titan, Geforce GTX 1080 Ti, 1080, 1070, 1060, 980 Ti, 980, 970, 960, 780 Ti, 780, 770, 760**, 680, 670, 660Ti, 660, 580, 570 AMD RX 590, 580, 570, 480, 470, R9 390X***, 390**, 380X***, 380, 290X***, 290***, 285***, 280X***, 280***, 270X, 270, R7 370, HD7970***, 7950***, 7870, 7850, 6970, 6950, 6870, 6850, 6790, 6770, 5870, 5850, 5830 *RTX uses the "A" brackets for mounting. **Supports long PCB variant only due to PCIe power connector interference. ***Some variations in AMD die height may require the use of a copper shim which is not included. |
Known Incompatibility - Graphics Cards | Nvidia GeForce RTX 2060 AMD RX Vega 64 |
Compatibility - AIO Liquid Coolers | NZXT Kraken Z73, Z63, X73, X63, X53, X72, X62, X52, X42, X61, X41, X31, X60, X40 Corsair H105, H110, H90, H75 (CW-9060015-WW only), H55, H50 (CW-906006-WW only) Thermaltake Water 3.0 Riing RGB 360, 280, 240, Red 280, 140, Water 3.0 Ultimate, Extreme S, Extreme, Pro, Performer Water 2.0 Extreme, Pro, Performer Antec KUHLER H2O 920V4, 620V4, 920, 620 Zalman LQ-320, LQ-315, LQ-310 |
Fan Dimensions | 92 x 92 x 25 mm |
Warranty | 2 years |
